SPECIFICATIONS:
RATED OUTPUT 15.3 KW / 21 MHP
RATED SPEED 3600 RPM
DISPLACEMENT 0.854 L / 52.1 CU. IN
NO. OF CYLINDERS 3 CYLINDERS
CYLINDER BORE X STROKE 70 MM X 74 MM / 2.76 IN X 2.91 IN
COMBUSTION SYSTEM - INDIRECT INJECTION, IN-LINE PUMP
ASPIRATION NATURAL
ALTERNATOR 12V - 125A
DRY WEIGHT WITHOUT GEAR 110 KG / 243 LBS
DIMENSIONS 694 MM X 463 MM X 600 MM
CONTROLS MECHANICAL
CERTIFICATIONS RCD 2 EPA TIER 3 EPA TIER 3C BSO II EMC
COMPOSIZIONE FORNITURA:
N. 1 INVERTITORE KM2P RID. 2,21
N. 2 SUPPORTO ELASTICO 100 X 3JH2/3GM/3YM
N. 2 SUPPORTO ELASTICO SD20 - SD40/3 230 X3GM/3YM
PROLUNGA YM MT. 4 CONNETTORI DEUTSCH
B20 KEYLESS PANEL GM/YM/JH4/JH5 V.N.16410030103
LIBRETTO USO E MANUTENZIONE MOTORE
